Evaporator can be delivered with coading of fins and epoxy painted cabinet. Please ask for extra price to have this option.

Rivacold RSIXB 3250 ED R744 evaporator – ceiling unit coolers


Price is excl. TAX.

Available on backorder

Code RSIXB3250ED
Refrigerating capacity 2535w
Cold Room Temp. 4 °C
Refrigerant R744
Range RSIX
Model Cubic Ceiling
Application MBP
Rows number 6
Total surface 11.26 m²
Defrosting 1300 W
Net weight 25.2 kg
Inlet connection 10 mm
Outlet connection 12 mm
Drain connection 1″ Gas (33mm)
Fin spacing 5.3
Circuit volume 1.88 dm³
Type Rotore esterno “ec”
Fan-motors no. 3
Diameter 254 mm
Power supply 230/1/50-60
Low speed 1200 rpm
High speed 1300 rpm
Power consumption 132 W
Current consumption 0.57 A
Air flow 1640 m³/h
Air throw 8.5 m
